低功耗
多模式
远距离
集成度高
低功耗蓝牙系列
用于蓝牙灯带、灯控、调光，两轮电动车仪表主控和蓝牙钥匙，蓝牙键鼠等消费类电子产品。
| 芯片型号 | 内核 | 多模 | FLASH | OTP | SRAM | EEPROM | 封装尺寸 | 发射功率 | 功耗（0dbm） | 文档下载 |
|---|---|---|---|---|---|---|---|---|---|---|
| WS8000 | 32M | BLE 5.0 2.4G | / | 16k | 16k | 可选 | SOP8 SOP16 | -12~10dBm | TX:15mA RX:16mA sleep:1uA | |
| WS8050 | 32M | BLE 5.0 2.4G | 64k | / | 16k | / | SOP16 | -12~10dBm | TX:15mA RX:16mA sleep:1uA | |
| WS8000S | 32M | BLE 5.0 2.4G | / | 16k | 6K | 可选 | SOP8 SOP16 | -20~8dBm | TX:18mA RX:16mA sleep:2uA | |
| WS8001S | 32M | BLE 5.0 2.4G USB | / | 16k | 6K | / | SOP8 | -20~8dBm | TX:18mA RX:16mA sleep:2uA | |
| WS8020S | 32M | BLE 5.0 2.4G USB | / | 16k | 6K | / | QFN16 | -20~8dBm | TX:18mA RX:16mA sleep:2uA | |
| WS8100 | 32M | BLE 5.0 | 512k | / | 40K | / | SOP16 QFN32 QFN48 | -20~7dBm | TX:9.5mA RX:8.5mA sleep:1uA | |
| WS8300 | 32M | BLE 5.0 BT 3.0 2.4G | 256k 512K | / | 28K | / | SOP16 QFN48 | -20~10dBm | TX:19mA RX:17mA sleep:1uA |
